FDA's Two-Panel System: What Must Appear Where on Your Food Label

Most first-time founders think about their food label as a design problem. They gather the content, hand it to a designer, and say “make it look good and compliant.” What they don’t realize is that FDA has already decided where most of that content must go — not approximately, but specifically, panel by panel.

Getting placement wrong does not require fixing a number. It requires redesigning the artwork. And if that discovery comes after the plates are cut and the first print run is already on pallets, you are looking at a reprint.

Here is how the two-panel system actually works.

What the Principal Display Panel Is

Under 21 CFR 101.1, the principal display panel (PDP) is the part of the label most likely to be displayed, presented, shown, or examined by a consumer at retail. On a box with multiple panels, it is the front face. On a bag, it is the broadest face most likely to be turned toward the shopper.

The regulation defines how to calculate the PDP area, because that number drives minimum type size requirements for at least one mandatory element:

• Rectangular packages: PDP area = height × width of the front panel
• Cylindrical or nearly cylindrical containers: PDP area = 40% × (height × circumference of the container), excluding tops, bottoms, flanges, and shoulders
• All other shapes: PDP area = 40% of the total surface of the container

For a cylindrical can, the practical implication is that the mandatory information on the PDP must appear within the 40% of the circumference most likely to face the consumer at retail. The geometry of the package shapes the label from the start.

What Must Appear on the PDP

Two elements are required to be on the principal display panel specifically. Not on any panel, but on the PDP.

Statement of Identity

The statement of identity is the common name of the food. Under 21 CFR 101.3, it must appear as one of the principal features of the PDP, in bold type, in lines generally parallel to the base of the package as it would be displayed for sale.

The size must be reasonably related to the most prominent printed matter on the PDP. A small “salsa” printed in a thin font at the bottom of a label dominated by a large recipe-style illustration does not satisfy this. The product name must be prominent. FDA’s guidance describes this as at least half the height of the largest text on the panel.

Net Quantity Declaration

The net quantity declaration — “NET WT 12 oz (340 g)” and so on — must also appear on the PDP, under 21 CFR 101.7. Three specifics matter here.

Placement: The declaration must appear in the bottom 30% of the PDP area, in lines generally parallel to the base. It cannot be tucked into a corner of the information panel or grouped with the ingredient list.

Separation: The declaration must appear as a distinct item, separated from other printed label information above or below it by at least a space equal to the height of the lettering used. To the left or right, it must be separated by at least a space equal to twice the width of the letter “N” in the type style used. The intent is that a consumer can find the weight without searching.

Type size: This is where the PDP area calculation from above connects to design specs. The minimum letter height for the net quantity declaration scales with PDP area under 21 CFR 101.7:

PDP area	Minimum letter height
5 sq in or less	1/16 inch
More than 5, up to 25 sq in	1/8 inch
More than 25, up to 100 sq in	3/16 inch
More than 100 sq in	1/4 inch or larger (consult 21 CFR 101.7 for full table)

A snack bag with a 20 square inch PDP needs net quantity text at least 1/8 inch tall. If a designer has set that text at 6-point in a condensed typeface to save room, the label is out of compliance regardless of what the weight says.

What the Information Panel Is

The information panel is defined in 21 CFR 101.2 as the label surface immediately contiguous and to the right of the PDP as observed by a person facing it. If that space is too small or otherwise unusable, the next panel to the right is used.

This is where most of the regulatory detail lives: the ingredient statement, allergen declaration, Nutrition Facts panel, and manufacturer name and address. All of these can appear either on the PDP or on the information panel, but in practice they live on the information panel because the PDP is occupied by the brand identity, product name, and imagery.

One rule governs everything on the information panel: all required information must appear together, without other intervening material. Under 21 CFR 101.2, mandatory label information cannot be broken up by unrelated text, decorative elements, or marketing copy. A label that places the ingredient list on the information panel, runs a tagline in the middle, and then continues with the allergen statement and Nutrition Facts below the tagline fails this requirement. The required information must be grouped as a continuous block.

The Allergen Statement’s Placement Requirement

The “Contains” statement gets its own placement rule within the information panel. Under FALCPA, the allergen declaration must appear immediately after or adjacent to the ingredient statement, in a type size no smaller than the type used for the ingredient list. It cannot be separated from the ingredient statement by unrelated text or design elements.

This is one of the more common placement errors. A designer who doesn’t know this rule may place the “Contains: Milk, Wheat, Sesame” line below the Nutrition Facts panel because it looks cleaner from a layout standpoint. That is a non-compliance, and reviewers flag it.

The 1/16 Inch Minimum

All information on the PDP or the information panel must meet a minimum type size of 1/16 inch in height, measured by the lowercase letter “o” in the typeface used, under 21 CFR 101.2. For most panels, this is a floor, not a standard. The net quantity declaration requires more than this minimum for anything but the smallest packages. The Nutrition Facts panel has its own prescribed type minimums under 21 CFR 101.9.

The practical implication for designers: label artwork needs to be reviewed at actual print dimensions, not at screen zoom. A type size that reads clearly at 150% in Illustrator can fall below the 1/16 inch floor when the label is printed at actual size.

Manufacturer Name and Address

Under 21 CFR 101.5, the label must include the name and place of business of the manufacturer, packer, or distributor, including street address, city, state, and ZIP code. The street address may be omitted if the business is listed in a current telephone or city directory. If the manufacturer is different from the brand on the label — common for co-packed products — the name must be qualified: “Manufactured for,” “Distributed by,” or similar.

This information goes on the information panel, grouped with the other mandatory information.

What This Means Before You Open a Design File

Before a designer opens a file, these decisions need to be settled:

1. Which surface is the PDP, and what is its area?
2. Where is the information panel relative to the PDP?
3. What are the minimum type sizes for the net quantity based on PDP area?
4. Which elements must be grouped continuously without interruption?
5. Is the “Contains” statement adjacent to the ingredient list, at the same or larger type size?

These are not questions that can be answered in the last round of artwork revisions. They shape the layout from the start. A label built without resolving them usually makes it through internal review and into production before a compliance check surfaces the issue.

The reprint cost that follows is the expensive way to learn the two-panel rule.

---
